12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm

Shandong Hightop Group
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm

Brand Name : HIGHTOP

Model Number : HT180

Place of Origin : Shandong China

Certification : CE,EPA ,EURO5

MOQ : 1 set

Price : Negotiation

Packaging Details : Wooden case

Delivery Time : 7-14 work days

Payment Terms : Western Union, MoneyGram, T/T, D/A, D/P, L/C

Supply Ability : 100 set per month

Function of leveling automatic : Yes

Rated power : 18.2KW

Pump maximum flow Gear : 42L/min

Overall dimension (L*W*H) : 4300x1160x2150mm

Battery capacity : 60Ah

Wheelbase : 1540mm

Pump maximum pressure : 200bar

Steering angle : 49°

Contact Now

HT180 12V Multi-functions Loader with Min. Turning Radius over Tyres 2257mm

Product Description:

Small Wheel Loader is a mini wheel loader which is suitable for a variety of applications. It is specially designed for loading, transporting and unloading material, and provides excellent performance, excellent reliability and cost-effectiveness. The loader is equipped with an independent wheel motor, a variable displacement piston system pump and a maximum dump height of 2167mm. It has a mini ground clearance of 200mm and an overall dimension of 4300x1160x2150mm. It is capable of fast and efficient loading, unloading and transportation of various materials, and is also suitable for a variety of construction tasks. The loader has high safety and reliability, and can effectively reduce fuel consumption. Its advanced design and excellent performance make it an ideal choice for your loading needs.

12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm

Features:

  • Compact Loader: Small Wheel Loader with 12V System Voltage and 1540mm Wheelbase.
  • Multi-functions Loader: Max. grade ability up to 30° and Min. turning radius over shovel up to 2691mm.
12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm

Technical Parameters:

Parameter Value
Product Name Small Wheel Loader
Min. turning radius over shovel 2691mm
Max.speed 20km/h
Operation weight 2000kg
Dumping angle 45°
Pump maximum pressure 200bar
Fuel tank 45L
Load over height 2634
Track base 872mm
Battery capacity 60Ah
Dinging depth 94mm

12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm

Applications:

HIGHTOP HT180 Small Wheel Loader is a multi-functions loader that is designed with small frame and compact structure. It is CE, EPA and EURO5 certified, and its minimum order quantity is 1 set. The price is negotiable, and the delivery time is 7-14 work days. Payment terms are Western Union, MoneyGram, T/T, D/A, D/P, L/C. The supply ability is 100 sets per month. The system pump type is Variable Displacement Piston, and the min. turning radius over tyres is 2257mm. The maximum shovel width is 1180mm, and the bucket capacity is 0.3cbm. This small wheel loader is perfect for small scale construction sites where reliable performance and high productivity are desired. It is also suitable for a wide range of complex construction tasks.

12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm

Customization:

Small Wheel Loader
  • Brand Name: HIGHTOP
  • Model Number: HT180
  • Place of Origin: Shandong China
  • Certification: CE,EPA ,EURO5
  • Minimum Order Quantity: 1 set
  • Price: Negotiation
  • Packaging Details: Wooden case
  • Delivery Time: 7-14 work days
  • Payment Terms: Western Union, MoneyGram, T/T, D/A, D/P, L/C
  • Supply Ability: 100 set per month
  • System Voltage: 12V
  • Dinging depth: 94mm
  • Max. grade ability: 30°
  • Wheelbase: 1540mm
  • Battery capacity: 60Ah
Features
  • Mini Wheel Loader
  • Small Wheel Loader
  • Compact Loader

Support and Services:

Small Wheel Loader Technical Support and Service

We offer technical support and service for our small wheel loader products. Our team of experienced professionals is available to provide comprehensive assistance and guidance on all aspects of your small wheel loader purchase and operation.

We can help you to select the right loader for your needs, install it and provide training on how to safely and effectively use it. We also offer maintenance and repair services to ensure that your small wheel loader is running at optimum efficiency.

For more information about our small wheel loader technical support and service, please contact us directly.

Packing and Shipping:

Packaging and Shipping for Small Wheel Loader:

Small wheel loaders are generally delivered to the customer's location in a secure shipping container. The shipping containers are designed to protect the wheel loader from any damage that may occur during transport. The packaging material used is also designed to protect the wheel loader from any external forces, such as vibration and shock.

The wheel loader will be secured to the shipping container with straps and/or bolts and secured with a steel cable. It is important to ensure that the loader is properly secured before shipping, as any movement of the wheel loader within the container can cause significant damage.

In some cases, additional packaging materials may be used to protect the wheel loader from any external forces, such as vibration and shock. This additional packaging may include foam inserts, plastic wrapping, or bubble wrap.

12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm12v Multi Functions Small Payloader With Min. Turning Radius Over Tyres 2257mm
